110 kV–220 kV Power Transformer

110 kV–220 kV Power Transformer

OMEGA supplies oil-immersed power transformers for 110 kV and 220 kV projects. Capacity, voltage ratios, winding arrangement, cooling and testing requirements are specified per project. The published parameter examples cover 110/121 kV configurations; request a separate datasheet for the proposed 220 kV unit.

Published 110 kV Transformer Configuration Reference

The current product page lists 110/121 kV configurations and a capacity range of 6.3–120 MVA. Confirm the available capacity and voltage combination for each proposed unit.

Transformer type

Oil-immersed power transformer

Published capacity range

6.3–120 MVA

Published HV ratings

110 / 121 kV

Published LV options

6.3 / 6.6 / 10.5 / 11 kV

Winding arrangement

Two-winding or three-winding

Three-winding voltage ratios

Confirm all three winding ratings

Published tapping reference

±2 × 2.5%; confirm mechanism and range

Vector group

Confirm for the selected winding arrangement

Cooling designation

Confirm in the approved datasheet

220 kV configuration

Request a project-specific datasheet

Specify frequency, insulation levels, impedance, losses, sound limits, accessories and transport restrictions in the purchase specification.

SZF-40000/110-35-10.5

Documents to Confirm for a 220 kV Transformer Order

  • For a 220 kV project, request a datasheet stating rated power, every winding voltage, insulation levels, frequency, vector group and impedance.
  • Specify the tap-changer type, operating range, cooling stages, monitoring devices and protection interfaces.

  • Agree on the inspection and test plan, acceptance criteria, report requirements and customer witness points.

  • Review the outline drawing, transport dimensions, shipping mass, oil shipment arrangement and site handling requirements before dispatch.

Transformer Testing & Technical Documents

Technical Datasheet

Test Requirements

Test Reports

110 kV–220 kV Power Transformer Procurement FAQ

No. Request a separate datasheet for the proposed 220 kV configuration.

The page lists 6.3–120 MVA. Confirm availability for the required voltage and winding arrangement.

Provide each winding’s voltage and power rating, frequency, vector group, impedance requirements, tapping, cooling, site conditions and applicable specification.

No. Confirm the cooling designation and rated power at each cooling stage in the approved datasheet.

No. Confirm the tap-changer type, range, steps and operating requirements separately.

Request the applicable report or design-verification documents. Confirm their relevance to the proposed design, rating and specified requirements.

110 kV–220 kV Power Transformer

OMEGA supplies oil-immersed power transformers for 110 kV and 220 kV projects. Capacity, voltage ratios, winding arrangement, cooling and testing requirements are specified per project. The published parameter examples cover 110/121 kV configurations; request a separate datasheet for the proposed 220 kV unit.

Published 110 kV Transformer Configuration Reference

The current product page lists 110/121 kV configurations and a capacity range of 6.3–120 MVA. Confirm the available capacity and voltage combination for each proposed unit.

Transformer type

Oil-immersed power transformer

Published capacity range

6.3–120 MVA

Published HV ratings

110 / 121 kV

Published LV options

6.3 / 6.6 / 10.5 / 11 kV

Winding arrangement

Two-winding or three-winding

Three-winding voltage ratios

Confirm all three winding ratings

Published tapping reference

±2 × 2.5%; confirm mechanism and range

Vector group

Confirm for the selected winding arrangement

Cooling designation

Confirm in the approved datasheet

220 kV configuration

Request a project-specific datasheet

Frequency / Phases

50 Hz / 3-phase

Specify frequency, insulation levels, impedance, losses, sound limits, accessories and transport restrictions in the purchase specification.

SZF-40000/110-35-10.5

Documents to Confirm for a 220 kV Transformer Order

  • For a 220 kV project, request a datasheet stating rated power, every winding voltage, insulation levels, frequency, vector group and impedance.
  • Specify the tap-changer type, operating range, cooling stages, monitoring devices and protection interfaces.

  • Agree on the inspection and test plan, acceptance criteria, report requirements and customer witness points.

  • Review the outline drawing, transport dimensions, shipping mass, oil shipment arrangement and site handling requirements before dispatch.

Transformer Testing & Technical Documents

Technical Datasheet

Test Requirements

Test Reports

110 kV–220 kV Power Transformer Procurement FAQ

No. Request a separate datasheet for the proposed 220 kV configuration.

The page lists 6.3–120 MVA. Confirm availability for the required voltage and winding arrangement.

Provide each winding’s voltage and power rating, frequency, vector group, impedance requirements, tapping, cooling, site conditions and applicable specification.

No. Confirm the cooling designation and rated power at each cooling stage in the approved datasheet.

No. Confirm the tap-changer type, range, steps and operating requirements separately.

Request the applicable report or design-verification documents. Confirm their relevance to the proposed design, rating and specified requirements.
